ChemSafe CS-9000 Series30L Fully Automatic Explosion-Proof Diluent Filling SystemATEX Zone 0 Certified • 45 Drums/Hr • ±0.05% Accuracy • Triple Containment • Industry 4.0 IntegrationCore Technical Spe
30L Fully Automatic Explosion-Proof Diluent Filling System
ATEX Zone 0 Certified ? 45 Drums/Hr ? ±0.05% Accuracy ? Triple Containment ? Industry 4.0 Integration
| Parameter | CS-9100 (Standard) | CS-9200X (ATEX Zone 0) | CS-9300P (Pharma-Grade) |
|---|---|---|---|
| Capacity | 30L (±0.05%) | 30L (±0.08%) | 30L (±0.03%) |
| Throughput | 45 Drums/Hr | 42 Drums/Hr | 40 Drums/Hr |
| Accuracy | ±0.05% Gravimetric | ±0.08% | ±0.03% |
| Viscosity Range | 0.5-500,000 cP | 1-300,000 cP | 0.3-1,000,000 cP |
| Explosion Protection | ATEX Zone 0/20 | IECEx Zone 0 | ATEX + cGMP |
| Filling Technology | Coriolis Mass Flow + Gear Pump | ATEX Diaphragm Pump | Peristaltic Pump (FDA) |
| Material Contact | Zirconium Alloy (R60702) | Hastelloy C276 | 316L EP (Ra<0.2μm) |
| Containment System | TripleLock?:<br>1. Nitrogen Inerting (O?<0.3%)<br>2. -0.8bar Vacuum Hood<br>3. Carbon Adsorption (99.98% VOC) | + Explosion Venting | VHP Sterilization |
| Static Control | Ionized Air Curtain<br>? 10? ions/cm3<br>? <0.1kV Surface Charge<br>? 0.1s Spark Detection | SIL-3 Certified | ESD Grounding |
| Leak Detection | Helium Mass Spectrometry<br>Sensitivity: 10?? mbar·L/s | Oxygen Analyzer | TOC Monitoring |
| Power | 480V/60Hz, 15kW | 24VDC Ex ia | 480V/60Hz, 14kW |
| Certifications | CE, ISO 9001 | ATEX/IECEx Zone 0 | FDA 21 CFR 177.2600 |
Safety Validation:
| Parameter | Performance | Certification Standard |
|---|---|---|
| O? Concentration | 0.25% ±0.05% | ATEX <8% |
| Surface Charge | <0.05kV | NFPA 77 <10kV |
| Response Time | 0.08s | IECEx <0.5s |
| Component | Technology | Performance |
|---|---|---|
| Coriolis Meter | Micro-Coriolis Sensor | ±0.01% Density Accuracy |
| Flow Control | Adaptive PID + AI Optimization | ±0.05% Consistency |
| Temp Compensation | Peltier System ±0.1°C | ±0.02% Error |
1. AGV Drum Loading → 2. Auto-Lid Removal → 3. Nitrogen Purging (O?<0.3%) → 4. Precision Filling (±0.05%) → 5. Vacuum Hood Retract → 6. Helium Leak Test → 7. VOC Recovery → 8. Torque-Sealing (50-150 N·m) → 9. Palletizing
Cycle Time: 80 seconds/drum
Chemical Processing
| Diluent Type | Technical Solution | Performance |
|---|---|---|
| Acetone | Zirconium Alloy Flow Path | 0.001mm/yr Corrosion |
| Toluene | Double Mechanical Seal | <10?? mbar·L/s Leak |
| Chlorinated Solvents | Kalrez?6375 Seals | 327°C Temp Resistance |
Pharmaceuticals
cGMP Compliance:
Data Integrity:
| System | 21 CFR Part 11 Feature |
|---|---|
| Audit Trail | Blockchain Timestamping |
| E-Signatures | RSA-2048 Encryption |
Paints & Coatings
| Feature | Innovation |
|---|---|
| Color Contamination | Isolated Fluid Paths |
| VOC Emission | 99.98% Carbon Adsorption |
| Static Accumulation | Ionized Air Curtain (10? ions/cm3) |
Uncompromised Safety & Precision
? Explosion-Proof Guarantee: | **Technology**| **Certification** | |-------------------------|--------------------------| | Intrinsic Safety| ATEX Ex ia IIC T4 | | Pressurized Enclosure | IECEx Ex px| | SIL-3 Monitoring | IEC 61508| ? Zero-Emission Operation: 1. 99.98% VOC Carbon Adsorption 2. Double Seal API 682 Plan 53B 3. Helium-Verified Containment ? Industrial 4.0 Ready: - OPC UA/PROFINET Connectivity - Predictive Maintenance AI - Digital Twin Integration
? ATEX 2014/34/EU Zone 0 (Category 1G) ? IECEx IEC 60079-0/1/7/11/31 ? FDA 21 CFR 177.2600 ? API 682 Plan 53B
BASF Solvent Packaging Facility:
"After implementing CS-9200X:
Output: 25 → 45 Drums/Hr (+80%)
VOC Emissions: ↓99.5% (Carbon Adsorption)
Leak Incidents: 8/year → 0
ROI Period: 8 months"
